PCB weight calculator

This tool helps you to calculate weight, area, volume and freigth cost for several types of printed circuit boards (PCBs). Material thickness, copper thickness, material type and layer quantity are all adjustable.

Fill in your PCB's characteristics like size, substrate thickness and layer quantity to get the total area, weight and volume calculated. Optionally, you may type in a freight cost per kilo gram in case you are going to forward the PCBs.

Tool - PCB Weight Calculation

Project name:

Layer count

Quantity

Stk.

Dimensions

mm (X)

mm (Y)

Copper thickness

Copper density

Carrier thickness FR4

Carrier thickness aluminum

Estimated Shipping costs

INR/Kg

PCB thickness

= mm

Weight

= Kg

Total Area

= m²

Weight per piece

= g

Total volume

= dm³

Shipping costs incl. 5% packing material

= INR

Tool - PCB Weight Calculation

Project name: Untitled project

Inputs

Layer count	2
Quantity	100 Stk.
Dimensions X	100 mm
Dimensions Y	100 mm
Copper thickness	35 µ
Copper density	75 %
Carrier thickness FR4	1.50 mm
Carrier thickness aluminum	0.1 mm
Estimated Shipping costs	150.00 INR/Kg

Results

PCB thickness	1.67 mm
Weight	4.19 Kg
Total Area	1.00 m²
Weight per piece	41.87 g
Total volume	1.67 dm³
Shipping costs incl. 5% packing material	659.49 INR

No responsibility is taken for the correctness of this information.

- No responsibility is taken for the correctness of this information. -

Note: The copper density of your PCBs may account for a significant share of the weight. You can adjust this value by changing the percentage. All calculations are based on the specific weight for a rectangular printed circuit. In case you need assistance, you can contact us at any time.
